LASER WELDING

Laser welding equipment has revolutionized the world of welding. It has a fiber laser of high useful life and quality. It is an easy-to-use equipment, it allows to make very fine welds without losing resistance.

With laser welding machines it is possible to make welds from 0.5 to 5mm, allowing to perfectly replace other welding methods..

Equipment::

t has pneumatic wheels, touch screen, interchangeable nozzles, security alarm system, high quality comfortable welding gun. It is available in different models and powers.

It has an integrated interactive control system that can vary the range, angle and width of the weld, allowing different techniques to be applied depending on the work to be done and depending on the surface to be welded.

It is possible to work with material addition or without it with an automatic wire feeding system.

Applications and industries:

It allows to reduce the thermal zone affected when working, and to exercise different joining and welding techniques.

It has great versatility, especially due to its wide range of penetration and laser power, and different applications of the equipment stand out, such as electronics, automotive parts, plating, tubes and pipes, etc.

Materials you can work with:

	WELDING
Stainless steel	√
Galvanised steel	√
Brass	√
Platinum	√
Aluminum	√
Titanium	√
Gold	√
Silver	√
Carbon steel	√
Certain plastics	√
Nickel	√

Process Comparison:

	TIG	LASER
Penetration	1.0-1.5mm	Up to 5mm
Speed	Slow welds	Very fast welds
Distortion	A lot of deformation	Minimum deformation
Skills needed	High skill welder	No great experience required

Joint configurations:

Información técnica:

MODELO	LC-SL 1000W	LC-SL 1500W	LC-SL 2000W
Potencia láser	100W	1500W	2000W
Voltaje	220v/380v	220v/380v	220v/380v
Consumo	<6kW	<8kW	<12kW
Profundidad de soldadura	0.5-3mm	0.5-4mm	0.5-5mm
Sistema de operación	Continuo
Longitud de onda	1070nM
Frecuencia de láser	50Hz-5KHz
Humedad del aire	10-90%
Estabilidad de la potencia	2%
Sistema de refrigeración	Por agua, control doble
Velocidad de soldadura	0-120mm/s
Largada del cable de fibra	Hasta 15m
Tamaño	1200x1100x700 aprox.
Peso	280kg
Temperatura del agua de refrigeración	5-45°C
